First Stage Regulator- Compact Model
Application
Designed to reduce tank pressure to a lower pressure for a second stage regulator in a two-stage system.
Features
- Type: First Stage
- Body: Die Cast Aluminum
- Maximum Inlet Pressure: 250 PSI / 17.2 bar
- Diaphram: NBR
- Valve Pad: NBR
Product Specification
| Compact Model No. | Inlet | Outlet | Outlet Pressure | Capacity in BTU/H LPG | Flow Rate in kg/h | |
| psig | mbar | |||||
| ZDK-822H-QH6 | 1⁄4" NPT | 1⁄2" NPT | 8-12 | 550-830 | 1,100,000 | 23 |
| ZDK-822H-PH6 | POL | 1⁄2" NPT | 1,800,000 | 38 | ||
| ZDK-822H-PT6 | POL | 3⁄4" NPT | 1,875,000 | 40 | ||
