Integral Two-Stage Regulator- Compact Model
Application
Integral Two-Stage units integrate first-stage regulator and second-stage regulator into a single compact unit. They are highly recommended for installations where the distance between the building being served and the tank is relatively short.
Features
- Type: Integral Two Stage Regulator
- Body: Die Cast Aluminum
- Maximum Inlet Pressure: 250 PSIG
- Diaphram: NBR Molded O-RING
- Orifice Size: 0.219"
Product Specification
| Compact Model No. | Inlet | Outlet | Outlet Pressure Setting | Capacity in BTU/H LPG | Flow Rate in kg/h | |
| "WC | mbar | |||||
| ZDK-8232-QH6 | 1⁄4" NPT | 1⁄2" NPT | 9.5"-13WC | 23-37 | 450,000 | 10 |
| ZDK-8232-PH6 | POL | 1⁄2" NPT | 450,000 | 10 | ||
| ZDK-8232-PT6 | POL | 3⁄4" NPT | 625,000 | 13 | ||
